KNX 10 inches touch screen

KNX

KNX 10 inches touch screen

0.00 Lei

Stoc:

Hardware / Software: Display: Power Supply: Standard Interfaces: Built-in Sensors: Quad-Core 1.2 GHz / 1GB DDR3 Ram / 8GB Nand flash Android 7.1 with Inspinia Application up to 1000 UI objects and 2000 BMS points Initial license: 500 BMS points / No HVAC (VRV/VRF) points IPS 10″ 1280 x 800 resolution 300 cd/m2 luminance with 5 point capacitive touchscreen Horizontal working mode 24VDC In POE IEEE 802.3at Power consumption max. 14W 1x LAN RJ45 10/100 Mbps interface 2x Add-On Ports (Optional Interface Ports) 5x Digital In 2x Digital Out (Dry Contact 2A / 24V DC) 1x Uni-port 2x 2 Watt Speakers 1x Mic Input Humidity sensor range 0% up to 100% RH Temperature sensor range -40°C up-to +125° Optional Interfaces (Ref.): KNX TP (A-KNX) Bticino (SCS) TP(A-SCS) iNELS Bus TP (A-iBUS) Galvanic isolated RS485 Modbus (A-GRS4) VRF mainline communication (A-VXX) Zigbee 3.0 (A-ZGB) Infrared (IRGW-UP, UPort w/ 6 IR Leds) Working Temperature & Humidity: -10°C – +60°C 5% – 90% at 25°C
